56 mm, 20 kN Fixed Round Compression Platen - G23-56

56 mm diameter round compression platen with a 20 kN maximum capacity

Specifications

• Platen size: 56 mm diameter
• Max force capacity: 20 kN (4,500 lbf)
• Platen body: hardened steel
• Temperature range: -70 to 350 C (-95 to 650 F)
• Connection: female 15.9 mm cup with 8 mm cross pin

Applications Include:

• ASTM E9
• ASTM D695
• ASTM D575
• ASTM D1621
• ISO 604
• ISO 844

Item sold as a single platen

     NOTE:  Order two platens to fit the top & bottom of your machine.
