100 N Wide Pincer Grip (150 mm W)
100 N Wide Pincer Grip (150 mm W)
Regular price
$0.00 USD
Regular price
Sale price
$0.00 USD
Shipping calculated at checkout.
The G341-150-F mechanical pincer grip body features an extra-wide 150x5 mm pyramid serrated clamping face rated for 100 N. Engineered to deliver uniform clamping force across broad flexible sheet technical textiles and wide foils.
Quantity
Couldn't load pickup availability
Need Assistance or a Custom Quote?
Contact our engineering team at 952-944-6534 or visit our Contact Us page for:
- Official Price Quotes & Purchase Orders
- Tax Exemption Certificate Submissions
- Application & Machine Compatibility Verification
Estimated Lead Time: 2 weeks
Technical Specifications & Overview +
- Model Number:
- G341-150-F
- Body Material:
- Nickel-coated steel
- Load Capacity:
- 100 N (22.5 lbf)
- Temp Range:
- 0°C to +180°C
- Max Opening:
- 0–3 mm (0–0.12 in)
- Jaw Surface:
- Pyramid
- Interface Side A Type:
- Female Socket
- Jaw Notes:
- Special extra-wide 150 mm jaw frame with integrated 0.6x45° pyramid serrated face and direct adapter mount.
- Applications:
- Micro-tensile peel and tension testing across extra-wide flexible sheet, technical textiles, and wide foils
- Primary Materials:
- Wide Foils, Technical Textiles, Flexible Sheet
- Recommended Machinery:
- Universal Testing Machines (UTM)
- Lead Time:
- 2 weeks
Capability Overview
The G341-150-F pincer grip body features an extra-wide 150x5 mm pyramid serrated clamping face rated for 100 N. Engineered to deliver uniform clamping force across broad flexible sheet technical textiles and wide foils.
Expert Engineering Note
Ultra-wide 150 mm frame distributes low clamping force across broad specimens without causing localized tearing.
